参数 |
Specifications |
技术指标/Technique |
额定容量 |
Capacity |
20,50,100,200N |
输出灵敏度 |
Rated output |
2.0±10%mV/V |
零点输出 |
Zero balance |
±0.05% F.S. |
非线性 |
Non-linearity |
0.1%F.S. |
滞后 |
Hysteresis |
0.1%F.S. |
重复性 |
Repeatability |
0.1%F.S. |
蠕变(30min) |
Creep(30min) |
0.1%F.S. |
温度灵敏度漂移 |
Temp.effect on output |
0.05%F.S./10℃ |
零点温度漂移 |
Temp.effect on zero |
0.05%F.S./10℃ |
输入电阻 |
Input impedance |
650/350±10Ω |
输出电阻 |
Output impedance |
650/350±10Ω |
绝缘电阻 |
Insulation |
≥5000MΩ/100VDC |
激励电压 |
Recommended excitation |
5~12V |
最大激励电压 |
Maximum excitation |
15V |
温度补偿范围 |
Compensated temp range |
-10~60℃ |
工作温度范围 |
Operation temp range |
-20~80℃ |
安全超载 |
Safe overload |
150%F.S. |
极限超载 |
Ultimate overload |
200%F.S. |
电缆线尺寸 |
Cable size |
Φ2×3000mm |
单件重量 |
Weight approx. |
0.1kg |
材料 |
Material |
Stainless Steel(不锈钢) |
防护等级 |
IP Class |
IP66 |
